Rectifiers Diode

STPR820D

www.iscsemi.com

1

FEATURES

· Power Factor Correction function

· Low reverse leakage current

· High surge capacity

APPLICATIONS

· PFC circuits

· solar inverters

· UPS systems

ABSOLUTE MAXIMUM RATINGS(Ta=25℃)

SYMBOL

PARAMETER

VALUE

UNIT

VRRM

Maximum Recurrent Peak Reverse Voltage

200

V

VRMS

Maximum RMS Voltage

140

V

VDC

Maximum DC Blocking Voltage

200

V

IF(AV)

Maximum Average Forward Rectified Current,TC=100℃

8

A

IFSM

Peak Forward Surge Current

8.3ms Single Half Sine Wave

Superimposed on Rated Load (Jedec Method)

90

A

TJ

junction temperature

150

℃

Tstg

storage temperature

-55~150

℃

THERMAL CHARACTERISTICS

SYMBOL

PARAMETER

MAX

UNIT

Rth j-c

Thermal resistance, junction-to-case

3.0

℃

/W
