background image
KW EELP41.RU
DATASHEET
DATASHEET
2 | Version 1.2 | 2025-07-10
SMARTLED™ 0603
KW EELP41.RU
The SMARTLED™ 0603 is the product of choice for status indi-
cation and symbol backlighting in electronics.
The small package size allows compact designs. The improved
corrosion robustness and increased junction temperature range
makes the devices from this series suitable for professional
industrial equipment and applications.
Applications
- Appliances & Tools
- Display Backlighting
- Factory Automation
- Home & Building Automation
- Projection & Display
- Static Signaling
- Transportation
Features
- Package: SMT package 0603, colored diffused resin
- Chip technology: Volume emitter on Sapphire (AlInGaN)
- Typ. Radiation: 130° (horizontal = 0°), 150° (vertical = 90°)
- Color: Cx = 0.3, Cy = 0.29 acc. to CIE 1931 (● white)
- Corrosion Robustness Class: 3B
- ESD: 8 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 3B)
