July 2008

Rev 4

1/16

16

STCS05

0.5 A max constant current LED driver

Features

■ Up to 40 V input voltage

■ Less than 0.5 V voltage overhead

■ Up to 0.5 A output current

■ PWM dimming pin

■ Shutdown pin

■ LED disconnection diagnostic

Applications

■ LED constant current supplying for varying

input voltages

■ Low voltage lighting

■ Small appliances LED lighting

■ Car LED lights

Description

The STCS05 is a BiCMOS constant current

source designed to provide a precise constant

current starting from a varying input voltage

source. The main target is to replace discrete

components solution for driving LEDs in low

voltage applications such as 5 V, 12 V or 24 V

giving benefits in terms of precision, integration

and reliability.

The current is set with external resistor up to 0.5

A with a ± 10 % precision; a dedicated pin allows

implementing PWM dimming.

An open-drain pin output provides information on

load disconnection condition.

SO-8

Table 1.

Device summary

Order code

Package

Packaging

STCS05DR

SO-8

2500 parts per reel

www.st.com
