PACKAGE MECHANICAL DATA

F126

A

C

C

D

D

B

REF.

DIMENSIONS

Millimeters

Inches

Min.

Typ.

Max.

Min.

Typ.

Max.

A

6.05

6.20

6.35

0.238

0.244

0.250

B

2.95

3.00

3.05

0.116

0.118

0.120

C

26

31

1.024

1.220

D

0.76

0.81

0.86

0.030

0.032

0.034
