STPR310D/F

STPR320D/F

February 1992 Ed: 1

ULTRA FAST RECOVERY RECTIFIER DIODES

Low cost single chip rectifier suited for switchmode

power supply and high frequency DC to DC conver-

ters.

Packaged in TO220AC and ISOWATT220AC, this

device is intended for use in low voltage, high fre-

quency inverters, free wheeling and polarity protec-

tion applications.

ABSOLUTE RATINGS (limiting values)

THERMAL RESISTANCE

DESCRIPTION

Symbol

Parameter

Value

Unit

IF(RMS)

RMS Forward Current

10

A

IF(AV)

Average Forward Current

δ =0.5

TO220AC

Tc = 125

°C3

A

ISOWATT220AC

Tc = 120

°C

IFSM

Surge Non Repetitive Forward Current

Tp = 10 ms

Sinusoidal

30

A

Tstg

Tj

Storage and Junction Temperature Range

- 65 to + 150

- 65 to + 150

°C

Symbol

Parameter

STPR

Unit

310D

310F

320D

320F

VRRM

Repetitive Peak Reverse Voltage

100

200

V

Symbol

Parameter

Value

Unit

Rth (j-c)

Junction-case

TO220AC

6.5

°C/W

ISOWATT220AC

8.5

.

SUITED FOR SMPS

.

LOW LOSSES

.

LOW FORWARD AND REVERSE RECOVERY

TIME

.

HIGH SURGE CURRENT CAPABILITY

.

HIGH AVALANCHE ENERGY CAPABILITY

STPR310D

STPR320D

STPR310F

STPR320F

TO220AC

(Plastic)

ISOWATT220AC

(Plastic)

K

A

K

A

1/6
