STTH2003CT/CG/CF/CR/CFP

2/8

Symbol

Parameter

Tests conditions

Min.

Typ.

Max.

Unit

Reverse leakage

current

Tj = 25°C

20

µA

Tj = 125°C

30

300

Forward voltage drop

Tj = 25°C

1.25

V

Tj = 125°C

0.85

1

Pulse test : * tp=5ms,

δ <2%

** tp = 380

µs, δ <2%

To evaluate the maximum conduction losses use the following equation :

2

(RMS)

STATIC ELECTRICAL CHARACTERISTICS (per diode)

Symbol

Parameter

Value

Unit

Junction to case

TO-220AB / D

Per diode

2.5

°C/W

Total

1.3

ISOWATT220AB

Per diode

3.9

Total

3.2

TO-220FPAB

Per diode

4.6

Total

4

TO-220AB / D

Coupling

0.1

ISOWATT220AB

Coupling

2.5

TO-220FPAB

Coupling

3.5

THERMAL RESISTANCES

Symbol

Tests conditions

Min.

Typ.

Max.

Unit

trr

Irr = 0.25 A

Tj=25

°C

25

ns

35

tfr

µs

Tj=25

°C

230

ns

3.5

V

Vcc = 200V

µs

Tj = 125°C

0.3

-

8A

RECOVERY CHARACTERISTICS
