25W Universal Input, Compact PCB

PSA25LS Open Frame with C14 Connector

US

C

Applications

• Networking

• Peripherals and Terminals

• Compact Equipment

• Microcomputers

Features

• Compact 2" x 5" PCB

• Low .85" Profile

• CISPR 22B; FCC B EMI

• Integral AC Connector

Mechanical Characteristics

Dimensions:• Length: 127mm (5in)

• Height: 21.5mm (0.846in)

• Width: 50.8mm (2in)

• Weight: 135gm (4.7oz)

Safety Approvals Pending

• cUL 1950, 3rd Edition

• TUV EN60950

• CE (Low Voltage Directive)

Output Specifications

16.5W

25.0W

+2%

+2%

+1%

+1%

50mV

50mV

5A

5A

0A

0A

3.3V

5.0V

PSA25LS-033

PSA25LS-050

Model

DC Output

Load

Ripple(1)

Regulation

Max

Voltage

Min.

Max.

P-P

Line

Load

Power

(1) Measured at full load by using a 12 inch twisted pair terminated with a 10mfd capacitor and a 0.1mfd

ceramic in parallel
