MICROSPACE PC/104

Data subject to change without notice

Feature Technical Specifications

FEATURES

FUNCTIONS

REMARKS

OPTIONS

Item code

MSM586SL

CPU

ELAN520

2nd Level Cache

—

Performance (MHz)

133

DRAM Min-Max (MB)

Soldered DRAM 32/64

Power Management

—

DiskOnChip Socket

yes

CompactFlash Socket

—

Mouse, Keyboard

yes

Floppy Interface

yes

IDE Interface

yes (LB)

Onboard IDE-Flash

DOC

COM1

RS232C*

422/458

COM2

RS232C*

422/458

COM3

RS232C*

422/458

COM4

RS232C*

422/458

LPT1

yes

USB

—

LAN

—

Audio

—

Video Controller

—

Video Datapath

—

Video Memory

—

CRT Video

—

LCD Interface

—

LCD Resolution

—

Video Input

—

EEPROM Support

yes

Watchdog

yes

Power Normal (typ)

5V/~630mA (@32/133)

Power Suspend

—

Cooling Type

passive

Operating Temp.

-25°C to +70°C

Extended Temp.

-40°C to +85°C

Weight (gr)

80

MTBF

> 200’000 h

* other options may be available, please contact our Sales office
