ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage, VPOS

5.5 V

VSET, ENBL

5.5 V

IFOP, IFON

5.5 V

RFIN Power

20 dBm

Internal Power Dissipation

1.2 W

26.5°C/W

8.7°C/W

Maximum Junction Temperature

150°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

1

As measured on the evaluation board. For details, see the Evaluation Board

section.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

ESD CAUTION
