■ CAUTIONS

1. Over voltage

A. Drive the product over the specified current/voltage rating per unit or per strip will damage

the product.

B. The product should not be used in reverse polarity.

C. It is recommended to use a power supply with overload (over-voltage, short circuit and

overheat) protection.

2. Hand soldering

A. It is recommended to use a tip temperature of 280

with a soldering iron capacity of 30W, if hand soldering of the connecting wire is required.

B. Be careful of the contaminations of hand soldering.

3. Storage & Handling

A. Open the anti-electrostatic bag only a short time before use.

B. The product is IP 65 dust and moisture resistance certified. However, cutting, drilling, marking,

and/or excess stress will damage the hermetic sealing and lost its waterproof capability.

C. During installation, excess mechanical stress will damage the product. The minimum

bending radius of curvature is 150mm (outwards, with LED on outer side).

The maximum twist angle is 15 degree.

WATERPROOF FLEXSTRIP LIGHT

BVM-SWFPC5 SERIES

Bright View Electronics

Date：2008/04/22

Page ：7 of 7

Version-B
