ADT7485A
http://onsemi.com
2
ABSOLUTE MAXIMUM RATINGS
Parameter
Rating
Unit
Supply Voltage (VCC)
4.0
V
Voltage on 12 V Pin
16
V
Voltage on 5.0 V Pin
7.0
V
Voltage on 2.5 V and VCCP Pins
3.6
V
Voltage on Any Other Pin (Including SST Pin)
−0.3 to +3.6
V
Input Current at Any Pin
±5.0
mA
Package Input Current
±20
mA
Maximum Junction Temperature (TJ Max)
150
°C
Storage Temperature Range
−65 to +150
°C
Lead Temperature, Soldering
IR Peak Re−flow Temperature
Lead Temperature (10 sec)
260
300
°C
ESD Rating
1500
V
Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the
Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect
device reliability.
NOTE: This device is ESD sensitive. Use standard ESD precautions when handling.
THERMAL CHARACTERISTICS
Package Type
qJA
qJC
Unit
10−Lead MSOP
206
44
°C/W
NOTE: qJA is specified for the worst−case conditions, that is, a device soldered in a circuit board for surface−mount packages.
PIN ASSIGNMENT
Pin No.
Mnemonic
Type
Description
1
VCC
Power supply
3.3 V ±10%. VCC is also monitored through this pin.
2
GND
Ground
Ground Pin.
3
D1+
Analog input
Positive Connection to Remote 1 Temperature Sensor.
4
D1−
Analog input
Negative Connection to Remote 1 Temperature Sensor.
5
12 V
Analog input
12 V Supply Monitor.
6
5.0 V
Analog input
5.0 V Supply Monitor.
7
VCCP
Analog input
Processor Core Voltage Monitor.
8
2.5 V
Analog input
2.5 V Supply Monitor.
9
ADD
Digital input
SST Address Select.
10
SST
Digital input/output
SST Bidirectional Data Line.
