1 / 9 page

September 2008

Rev 5

1/9

9

TIP35C

TIP36C

Complementary power transistors

Features

■ Low collector-emitter saturation voltage

■ Complementary NPN - PNP transistors

Applications

■ General purpose

■ Audio amplifier

Description

The devices are manufactured in planar

technology with “base island” layout. The

resulting transistors show exceptional high gain

performance coupled with very low saturation

voltage.

.

Figure 1.

Internal schematic diagrams

Table 1.

Device summary

TO-247

1

2

3

Order code

Marking

Package

Packaging

TIP35C

TO-247

Tube

TIP36C
