M692SDM Datasheet Rev 2.0

5 of 5

Revised 27Jan2012

Integ r a t ed De vice Te chno log y, Inc.

●

Ne t c o m E a st

●

ww w. i d t . c o m

●

tel (774 ) 3 48-160 0

M692SDM

SIGE SINGLE FREQUENCY VCSO

P e r f o r m a nc e Da t a sh ee t

ORDERING INFORMATION

Part Numbering Scheme

Figure 4: Part Numbering Scheme

Example Order Numbers

M692SDM Standard Output Frequencies & Order

Codes

Consult IDT for the availability of other frequencies

For Output Frequencies (MHz)

Frequency

Order Part Number

M692SDM-xxx

1747.623000

M692SDM-R01

1747.030837

M692SDM-R02

Table 7: Example Order Numbers

M692SD

Part Number:

M680-01 -

See Table 8 at right for frequency order codes.

Device Number

Consult IDT for other frequencies and order codes.

M692SDM

Output Frequency Order Code

xxx

Output Frequency

Code

Output Frequency

MHz

R01

1747.623000

R02

1747.030837

R03

1748.366885

R04

1748.793733

Table 8: M692SDM Standard Output Frequencies & Order
