1 / 3 page

TO-8-1

Semiconductor Group

1

02.97

Silicon Piezoresistive

Relative Pressure Sensor

KPY 33-R

Features

• Low pressure and temperature hysteresis

• Fast response

• High sensitivity and linearity

• Fatigue free monocrystaline silicon diaphragm

giving high load cycle stability

• High long term stability

• Metal Housing

Type and

Marking

Symbol

Pressure

Range

Unit

Ordering Code

KPY 33-R

P

0 … PN

0

… 0.1

bar

Q62705-K151

Pin Configuration

1

+V

OUT

2+

V

IN

3

Not connected

4

Temperature sensor

5

Temperature sensor

6

Shielding, to be connected

to +

V

in

7

− V

OUT

8

− V

IN
