1 / 3 page

Similar to TO-39-3

Semiconductor Group

1

1998-05-11

Silicon Piezoresistive

Pressure Sensor

KPY 62-RK

KPY 66-RK

Features

• Low pressure and temperature hysteresis

• Fast response

• High sensitivity and linearity

• Fatigue free monocrystaline silicon diaphragm

giving high load cycle stability

• High long term stability

• Built in silicon temperature sensor

• Metal housing

Type and

Marking

Symbol

Pressure Range

Unit

Ordering Code

KPY 62 RK

P

0

… P

N

0

… 600

mbar

Q62705-K319

KPY 63 RK

0

… 1.6

bar

Q62705-K320

KPY 64 RK

0

… 4

Q62705-K321

KPY 65 RK

0

… 10

Q62705-K322

KPY 66 RK

0

… 25

Q62705-K292

Pin Configuration

1

Temp.- Sensor

(typ.

R

25 = 2 kΩ)

2

Not connected

3+

V

IN; Temperature sensor

4

− V

OUT

5

No pin

6

Shielding, to be connected

to +

V

IN

7

− V

IN

8+

V

OUT
