UNISONIC TECHNOLOGIES CO., LTD

UTD436

Preliminary

Power MOSFET

www.unisonic.com.tw

1 of 6

QW-R502-258.a

N-CHANNEL ENHANCEMENT

MODE

DESCRIPTION

The UTD436 uses UTC’s advanced trench technology to

provide excellent RDS(ON), low gate charge and operation with low

gate voltages. This device is suitable for use as a load switch or in

PWM applications.

FEATURES

* RDS(ON)<7.5mΩ @VGS=10V, ID =20A

* RDS(ON)<13mΩ @VGS=4.5V, ID =20A

* Low capacitance

* Low gate charge

* Fast switching capability

* Avalanche energy specified

SYMBOL

1.Gate

3.Source

2.Drain

Lead-free:

UTD436L

Halogen-free: UTD436G

ORDERING INFORMATION

Ordering Number

Pin Assignment

Normal

Lead Free

Halogen Free

Package

1

2

3

Packing

UTD436-TN3-R

UTD436L-TN3-R

UTD436G-TN3-R

TO-252

G

D

S

Tape Reel

UTD436-TN3-T

UTD436L-TN3-T

UTD436G-TN3-T

TO-252

G

D

S

Tube
