SE2520L-R datasheet(3/8 Pages) SIGE

3 / 8 page

SE2520L

RangeCharger™ 2.4GHz Power Amplifier IC

Final

Absolute Maximum Ratings

These are stress ratings only. Exposure to stresses beyond these maximum ratings may cause permanent damage

to, or affect the reliability of the device. Avoid operating the device outside the recommended operating conditions

defined below. This device is ESD sensitive with an ESD rating of < 600V. Handling and assembly of this device

should be at ESD protected workstations.

Symbol

Parameter

Min.

Max.

Unit

VCC

Supply Voltage (VCC0, VCC1, VCC2)

-0.3

+3.6

VCTL

Control Voltage

-0.3

VCC

VEN

Power Amplifier Enable

-0.3

VCC

RF Input Power

dBm

TSTG

Storage Temperature Range

-40

+150

°C

Maximum Junction Temperature

+150

°C

Recommended Operating Conditions

Symbol

Parameter

Min.

Typ.

Max.

Unit

Operating Temperature

-40

+85

°C

VCC

Supply Voltage

2.7

3.3

3.6

DC Electrical Characteristics

Conditions: V

CC0 = VCC1 = VCC2 = VEN = 3.3V, VCTL = 1.6V, PIN = -8dBm, TA = 25°C, f = 2.45GHz, using SiGe

SE2520L-EV1 Evaluation Board.

Symbol

Parameter

Min.

Typ.

Max.

Unit

ICC

Supply Current, VCTL = 1.6V, PIN = -8dBm

110

130

ICC(sat)

Supply Current (sat) @ PIN = 2dBm

140

175

∆IccTEMP

Supply Current variation over temperature from

TA = 25

°C

(-40

°C < TA < +85°C)

VCTL

PA Output Power Control Voltage Range

0.1

1.6

ICTL

Current Sunk by VCTL Pin

100

µA

Logic High Voltage

2.0

VEN

Logic Low Voltage

0.8

ISTBY

Leakage Current when VEN = 0V, VCTL = 0V

0.1

200

µA

15-DST-01 Rev 4.8 Oct 28/02

3 of 8
