Response format
M24LR16E-R
72/143
Doc ID 018932 Rev 8
20.2
Response error code
If the Error_flag is set by the M24LR16E-R in the response, the Error code field is present
and provides information about the error that occurred.
Error codes not specified in Table 32 are reserved for future use.
Table 32.
Response error code definition
Error code
Meaning
03h
The option is not supported.
0Fh
Error with no information given.
10h
The specified block is not available.
11h
The specified block is already locked and thus cannot be locked again.
12h
The specified block is locked and its contents cannot be changed.
13h
The specified block was not successfully programmed.
14h
The specified block was not successfully locked.
15h
The specified block is read-protected.
