5. Waveform Control Knobs – Control channel,

zoom, math and memory traces with the

multiplexed vertical and horizontal knobs

6. Dedicated Cursor Knob – Select type of cursor,

position them on your signal, and read values

without ever opening a menu

7. Dedicated buttons to quickly access popular

debug tools.

8. Easy connectivity with two convenient USB

ports on the front, two on the side

9. Rotating and Tilting Feet provide 4 different

viewing positions

10. Auxiliary Output and Reference Clock

Input/Output connectors for connecting to

other equipment

11. USBTMC (Test and Measurement Class) port

simplifies programming

Document and Share:

• Quickly save all files with LabNotebook

• Create custom reports with LabNotebook

• Save to internal solid state or network drive

• Print to a USB printer

• Save to USB memory stick

• Connect with LAN or GPIB

• View data on a PC with free WaveStudio utility
