ADF4106

Data Sheet

Rev. E | Page 4 of 24

Parameter

B Version1

B Chips2 (typ)

Unit

Test Conditions/Comments

NOISE CHARACTERISTICS

Normalized Phase Noise Floor

(PNSYNTH)11

–223

dBc/Hz typ

PLL loop B/W = 500 kHz, measured at 100 kHz

offset

Normalized 1/f Noise (PN1_f)12

−122

dBc/Hz typ

10 kHz offset; normalized to 1 GHz

Phase Noise Performance13

@ VCO output

900 MHz14

–92.5

−92.5

dBc/Hz typ

@ 1 kHz offset and 200 kHz PFD frequency

5800 MHz15

−76.5

dBc/Hz typ

@ 1 kHz offset and 200 kHz PFD frequency

5800 MHz16

−83.5

dBc/Hz typ

@ 1 kHz offset and 1 MHz PFD frequency

Spurious Signals

900 MHz14

–90/–92

dBc typ

@ 200 kHz/400 kHz and 200 kHz PFD frequency

5800 MHz15

–65/–70

dBc typ

@ 200 kHz/400 kHz and 200 kHz PFD frequency

5800 MHz16

–70/–75

dBc typ

@ 1 MHz/2 MHz and 1 MHz PFD frequency

1 Operating temperature range (B Version) is –40°C to +85°C.

2 The B chip specifications are given as typical values.

3 This is the maximum operating frequency of the CMOS counters. The prescaler value should be chosen to ensure that the RF input is divided down to a frequency that

is less than this value.

4 AVDD = DVDD = 3 V.

5 AC coupling ensures AVDD/2 bias.

6 Guaranteed by design. Sample tested to ensure compliance.

7 TA = 25°C; AVDD = DVDD = 3 V; P = 16; RFIN = 900 MHz.

8 TA = 25°C; AVDD = DVDD = 3 V; P = 16; RFIN = 2.0 GHz.

9 TA = 25°C; AVDD = DVDD = 3 V; P = 32; RFIN = 6.0 GHz.

10 TA = 25°C; AVDD = DVDD = 3.3 V; R = 16383; A = 63; B = 891; P = 32; RFIN = 6.0 GHz.

11 The synthesizer phase noise floor is estimated by measuring the in-band phase noise at the output of the VCO and subtracting 20 log N (where N is the N divider

value) and 10 log FPFD. PNSYNTH = PNTOT − 10 log FPFD − 20 log N.

12 The PLL phase noise is composed of 1/f (flicker) noise plus the normalized PLL noise floor. The formula for calculating the 1/f noise contribution at an RF frequency, fRF,

and at a frequency offset, f, is given by PN = PN1_f + 10 log(10 kHz/f) + 20 log(fRF/1 GHz). Both the normalized phase noise floor and flicker noise are modeled in

ADIsimPLL.

13 The phase noise is measured with the EV-ADF4106SD1Z evaluation board and the Agilent E4440A Spectrum Analyzer. The spectrum analyzer provides the REFIN for

the synthesizer (fREFOUT = 10 MHz @ 0 dBm).

14 fREFIN = 10 MHz; fPFD = 200 kHz; Offset Frequency = 1 kHz; fRF = 900 MHz; N = 4500; Loop B/W = 20 kHz.

15 fREFIN = 10 MHz; fPFD = 200 kHz; Offset Frequency = 1 kHz; fRF = 5800 MHz; N = 29000; Loop B/W = 20 kHz.

16 fREFIN = 10 MHz; fPFD = 1 MHz; Offset Frequency = 1 kHz; fRF = 5800 MHz; N = 5800; Loop B/W = 100 kHz.

TIMING CHARACTERISITICS

AVDD = DVDD = 3 V ± 10%, AVDD ≤ VP ≤ 5.5 V, AGND = DGND = CPGND = 0 V, RSET = 5.1 kΩ, dBm referred to 50 Ω, TA = TMAX to TMIN,

unless otherwise noted.

Table 2.

Parameter

Limit1 (B Version)

Unit

Test Conditions/Comments

ns min

DATA to CLOCK Setup Time

ns min

DATA to CLOCK Hold Time

ns min

CLOCK High Duration

ns min

CLOCK Low Duration

ns min

CLOCK to LE Setup Time

ns min

LE Pulse Width

1 Operating temperature range (B Version) is –40°C to +85°C.
