EE-SY671/672

6

(Unit: mm)

Dimensions

Tolerance class IT16 applies to dimensions in this datasheet unless otherwise specified.

Sensors

Accessories (Order Separately)

*Refer to Accessories for details.

19

19

Two, 3.2 dia. holes

13.4

12.2

25.4

(31.4)

(25)

6.2

2.54

0.2

16.7

8.3

14.15

5.5

4.1

13.2

6.95

6.35

Sensitivity

adjuster

Sensing window (back) (12.2

× 4.1)

Indicator window

0.3

0.7

0.6

(3)

(2)

(4)

(1)

Two, 3.8 dia.

holes

EE-SY671

Terminal Arrangement

(1)

+

Vcc

(2)

L

L

(3)

OUT

OUTPUT

(4)

−

GND (0 V)

19

19

Two, 3.2 dia. holes

13.4

25.4

(31.2)

(25)

6.2

2.54

16.7

8.3

5.5

13.2

6.95

6.35

Sensitivity

adjuster

Sensing window (12.2

× 5.15)

Indicator window

0.3

0.7

0.6

(3)

(2)

(4)

(1)

Two, 3.8 dia.

holes

EE-SY672

Terminal Arrangement

(1)

+

Vcc

(2)

L

L

(3)

OUT

OUTPUT

(4)

−

GND (0 V)
