Through Hole Power Inductors

THAR0806 Type

Mechanical Dimension:

RoHS compliant.

High current ( lsat up to 40A ) though hole type.

Magnetically shielded, suitable for hight density mounting.

High energy storage and low DCR.

Ideal for power source circuits, DC-DC converter,

DC-AC inverters inductor application.

In addition to the standard versions shown here,

customized

inductors are available to meet your exact requirements.

Features

DELTA ELECTRONICS, INC.

TEL: 886-3-3591968; FAX: 886-3-3591991

http://www.deltaww.com

150

B

A

G

G

2x H

E

D

C

F

1. Lo is the initial inductance and the tolerance is 20%.

2. Isat is the DC current which cause the inductance drop less than 20% of its nominal inductance without current.

O

OO

RECOMMENDED PAD PATTERNS

UNIT : mm/inch

A = 8.20 / 0.323 Max.

B = 8.20 / 0.323 Max.

C = 3.50

0.5 / 0.138

0.020

D = 6.00 / 0.236 Max.

PART NO.

(Adc)

(Adc)

F 0.1

(mm/inch)

G 0.5

(mm/inch)

H Max.

(Mm/inch)

DCR

(m )

8%

(uH)

1

L

2

3

E 0.5

(mm/inch)

THAR0806-R47

0.47

2.6

34

19

6.3 / 0.248

0.8 / 0.031

4.5 / 0.177

1.2 / 0.047

THAR0806-0R6

0.60

2.6

30

19

6.3 / 0.248

0.8 / 0.031

4.5 / 0.177

1.2 / 0.047

THAR0806-0R8

0.80

3.0

27

18

6.3 / 0.248

0.8 / 0.031

4.5 / 0.177

1.2 / 0.047

THAR0806-1R0

1.00

4.7

22

15

6.3 / 0.248

0.7 / 0.028

4.5 / 0.177

1.1 / 0.043

THAR0806-1R2

1.20

4.7

21

15

6.3 / 0.248

0.7 / 0.028

4.5 / 0.177

1.1 / 0.043

THAR0806-1R5

1.50

6.0

15

12

6.8 / 0.268

0.6 / 0.024

5.0 / 0.197

1.0 / 0.039

THAR0806-1R8

1.80

10.4

14

10

6.8 / 0.268

0.5 / 0.020

5.0 / 0.197

0.9 / 0.035

THAR0806-2R0

2.00

10.4

12

9

6.8 / 0.268

0.5 / 0.020

5.0 / 0.197

0.9 / 0.035

THAR0806-2R5

2.50

11.5

10

8

6.8 / 0.268

0.5 / 0.020

5.0 / 0.197

0.9 / 0.035

0

0. 2

0. 4

0. 6

0. 8

1

1. 2

0

10

20

30

40

DC BIAS (A)
