STPS2L40U データシート(PDF) 1 Page - STMicroelectronics |
|
|
|||||||||||||||||||||||||||||
STPS2L40U データシート(HTML) 1 Page - STMicroelectronics |
|
|
1 / 10 page  September 2008 Rev 4 1/10 10 STPS2L40 Low drop power Schottky rectifier Features ■ Very small conduction losses ■ Negligible switching losses ■ Low forward voltage drop ■ Surface mount miniature package ■ Avalanche capability specified ■ ECOPACK2 ® halogen-free component (SMAflat and SMBflat) Description Single chip Schottky rectifiers suited to Switched Mode Power Supplies and high frequency DC to DC converters. Packaged in SMB, low profile SMB and low profile SMA, this device is especially intended for surface mounting and used in low voltage, high frequency inverters, free wheeling and polarity protection applications. Table 1. Device summary IF(AV) 2 A VRRM 40 V Tj (max) 150 °C VF(max) 0.34 V K A K A K A SMB STPS2L40U SMBflat STPS2L40UF SMAflat STPS2L40AF www.st.com |
