STBB2

Absolute maximum ratings

3

Absolute maximum ratings

Note:

Absolute maximum ratings are those values beyond which damage to the device may occur.

Functional operation under these conditions is not implied.

Table 3. Absolute maximum ratings

Symbol

Parameter

Value

Unit

VIN, VINA, VINA1

Supply voltage

-0.3 to 7.0

V

SW1,SW2

Switching nodes

-0.3 to 7.0

V

VOUT

Output voltage

-0.3 to 7.0

V

MODE, EN, BP, VSEL

Logic pins

-0.3 to 7.0

V

FB

Feedback pin

-0.3 to 6.0

V

ESD

Human body model

± 2000

V

Charged device model

± 500

Operating ambient temperature

-40 to 85

°C

Maximum operating junction temperature

150

°C

Storage temperature

-65 to 150

°C

Table 4. Thermal data

Symbol

Parameter

Value

Unit

Thermal resistance junction-ambient

°C/W

1.

PCB condition: JEDEC standard 2s2P(4-layer).
