Maximum ratings

LDK120

6/24

DocID023965 Rev 4

4

Maximum ratings

Note:

Absolute maximum ratings are those values beyond which damage to the device may occur.

Functional operation under these conditions is not implied. All values are referred to GND.

Table 2. Absolute maximum ratings

Symbol

Parameter

Value

Unit

DC input voltage

- 0.3 to 7

V

DC output voltage

V

Enable input voltage

V

ADJ/Bypass pin voltage

2

V

Output current

Internally limited

mA

Power dissipation

Internally limited

mW

Storage temperature range

- 65 to 150

°C

Operating junction temperature range

- 40 to 125

°C

Table 3. Thermal data

Symbol

Parameter

SOT23-5L

SOT323-5L

DFN-6L

Unit

Thermal resistance junction-ambient

160

246

237

°C/W

Thermal resistance junction-case

68

134

104

°C/W
