BAT54TS

Preliminary

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R601-068.b

ABSOLUTE MAXIMUM RATINGS

PARAMETER

SYMBOL

RATINGS

UNIT

Peak Repetitive Reverse Voltage

30

V

Continuous Forward Current

0.2

A

Peak Forward Surge Current, 1.0s Single Half Sine-Wave

Superimposed on Rated Load (JEDEC Method)

0.6

A

10

pF

Storage Temperature

-55~+150

°C

Operating Junction Temperature

-55~+150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

THERMAL CHARACTERISTICS

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

667

°C/W

ELECTRICAL CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Maximum Instantaneous Forward Voltage

0.24

V

0.32

V

0.4

V

0.5

V

0.8

V

DC Reverse Current at Rated DC Blocking Voltage

2

μA
