Maximum ratings

Stressing the device above the ratings listed inTable 4 may cause permanent damage to the

device. These are stress ratings only and operation of the device at these or any other

conditions above those indicated in Recommended operating conditions of this specification

is not implied. Exposure to absolute maximum rating conditions for extended periods may

affect device reliability.

Recommended operating conditions

Table 4.

Absolute maximum ratings

Symbol

Parameter

Value

Unit

Supply voltage

-0.3 to 4.6

V

Supply voltage

-0.3 to 6.5

V

DC control input voltage

-0.3 to 6.5

V

V

V

DC input diode current

-20

mA

DC output current

±25

mA

DC output current

±25

mA

Short-circuit duration, continuous

40

mA

Power dissipation

500

mW

Storage temperature

-65 to 150

Lead temperature (10 seconds)

300

ESD

Electrostatic discharge protection (HBM)

±2

kV

Table 5.

Recommended operating conditions

Symbol

Parameter

Min.

Typ.

Max.

Unit

Supply voltage

1.65

–

3.6

V

Supply voltage

–5.5

V

supply referred)

0–

3.6

V

0

–

V

0

–

V

Operating temperature

-40

–

85

dt/dV

Input rise and fall time

0

–

1

ns/V
