DocID4578 Rev 24

25/42

M24C32-W M24C32-R M24C32-F M24C32-X M24C32-DF

DC and AC parameters

Table 13. Memory cell data retention

Parameter

Test condition

Min.

Unit

Data retention(1)

1. The data retention behavior is checked in production, while the data retention limit defined in this table is

extracted from characterization and qualification results.

TA = 55 °C

200(2)

2. For products identified by process letter K or T (previous products were specified with a data retention of 40

years at 55°C).

Year

Table 14. DC characteristics (M24C32-W, device grade 6)

Symbol

Parameter

Test conditions (in addition to those

in Table 6)

Min.

Max.

Unit

ILI

Input leakage current

(SCL, SDA, E2, E1,

E0)

VIN = VSS or VCC, device in Standby

mode

-± 2

µA

ILO

Output leakage

current

SDA in Hi-Z, external voltage applied

on SDA: VSS or VCC

-± 2

µA

ICC

Supply current (Read)

2.5 V < VCC < 5.5 V, fc = 400 kHz

(rise/fall time < 50 ns)

-2

2.5 V < VCC < 5.5 V, fc = 1 MHz(1)

(rise/fall time < 50 ns)

1. Only for devices identified with process letter K or T.

-2.5

ICC0

Supply current (Write)

During tW,

2.5 V ≤ VCC ≤ 5.5 V

-5(2)

2. Characterized value, not tested in production.

ICC1

Standby supply

current

Device not selected(3),

VIN = VSS or VCC, VCC = 2.5 V

3. The device is not selected after power-up, after a Read instruction (after the Stop condition), or after the

completion of the internal write cycle tW (tW is triggered by the correct decoding of a Write instruction).

-2

µA

Device not selected(3),

VIN = VSS or VCC, VCC = 5.5 V

-3(4)

4. 5 µA for previous devices identified by process letter P.

µA

VIL

Input low voltage

(SCL, SDA, WC, E2,

E1, E0)(5)

5. Ei inputs should be tied to Vss (see Section 2.3).

–0.45

0.3 VCC

VIH

Input high voltage

(SCL, SDA)

-0.7 VCC

6.5

Input high voltage

(WC, E2, E1, E0)(6)

6. Ei inputs should be tied to Vcc (see Section 2.3).

-0.7 VCC VCC+1

VOL

Output low voltage

IOL = 2.1 mA, VCC = 2.5 V or

IOL = 3 mA, VCC = 5.5 V

-0.4
