WPANTDP071-R1A

Mag Mount L1 GPS Antenna

Picture of the Part

Application

The WPANTDP071-R1A antenna is a Mag-mount L1 band passive GPS Antenna for automobile applications. The

standard cable length for this antenna is 3 meters and the standard connector is SMA. It can be also configured for

different cable lengths and connectors.

WP Wireless can assist your engineers to optimize mounting positions for these antennas in your specific application

and can further assist to trouble shoot system integration issues such as TRP/TIS and FCC requirements. WP

Wireless specializes in developing customized Antenna solutions. Please contact sales@wp-wireless.com with your

specific application requirements.

Electrical Properties

Parameter

Antenna Performance

Operating Frequency

1567 – 1583 MHz

Recommended Impedance of the

customer Radio Module[

Ω]

50Ω

VSWR – Typical

<2:1

Peak Gain [dBi] (Typical)

3 dBi

Polarization

RHCP

Accepted Power [W] (Max)

2 Watts
