PVT412PBF データシート(PDF) 4 Page - International Rectifier |
|
|
|||||||||||||||||||||||||||||
PVT412PBF データシート(HTML) 4 Page - International Rectifier |
|
|
4 / 6 page  Series PVT412PbF 4 www.irf.com © 2015 International Rectifier Submit Datasheet Feedback May 18, 2015 Delay Time (microseconds) 50 100 200 500 20 1000 2000 20 10 5 3 toff tdly ton Figure 7. Typical Delay Times Figure 9. Typical Output Capacitance ID 10% tdly ton toff ILED 90% Figure 8. Delay Time Definitions Figure 5. Typical Normalized Off-State Leakage Figure 6. Input Characteristics (Current Controlled) CAUTION: Provide current limiting so that 25 mA max. steady-state control current rating is not exceeded. |
|
|
