A

B

C

D

4

3

2

1

D

C

B

A

1

2

4

3

RP-SMA MALE CABLE END

CRIMP FOR RG58 CABLE

0.276

(7.00)

0.079

(2.00)

RECOMMENDED CABLE STRIPPING DIMENSIONS

0.118

(3.00)

RG-58 Cable

1.

Solder the socket to the center conductor.

2.

Insert the socket, center conductor, and insulator into the body

until the top of the socket is even with the white insulation in the body.

3.

Wrap the braid around the tail of the body and crimp the ring with a

hex crimp tool.

CONREVSMA007-R58 ASSEMBLY INSTRUCTIONS

Description

Material

Finish

Body

Socket

Insulation

Nickel

Teflon

Gold

Teflon

Brass

BE CU

Washer

PH Bronze

Gold

Gasket

Rubber

SI Rubber

Crimp Ring

Nickel

Brass

CONNECTOR CITY

159 ORT LANE

MERLIN, OR 97532

PH (541)-471-6256

FAX (541)-471-6251

Date:

Sheet 1 of 1

Revision:

Title

Part No.

Dimensions:

CONREVSMA007-R58

1.0

INCHES (mm)

6/1/2006

0.500

(12.70)

Ø0.256

(6.50)

0.240

(6.10)

Ø0.039

(1.00)

Ø0.049

(1.25)

Ø0.024

(0.60)

PIN CHUCK

0.2x2x2 GROOVE

0.276

(7.00)

0.656

(16.65)

Ø0.126

(3.20)

Ø0.177

(4.50)

1/4-36UNF-2B

THREADS

H0.311

(7.90)

SIDE VIEW

SOCKET

CRIMP RING
