UCM101

Preliminary

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

3 of 4

www.unisonic.com.tw

QW-R502-933.a



ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

-0.6~20

V

Voltage on all Other Pins

V

+/-6

V

Package Power Dissipation

(De-rate to zero at 150°C)

300

mW

Operating Temperature

-40~125

°C

Storage Temperature

-55~150

°C

Maximum Junction Temperature

150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



RECOMMENDED OPERATIONG CONDITIONS

PARAMETER

SYMBOL

RATINGS

UNIT

Common-Mode Sense Input Range

2.7~20

V

Current Direction Flag Output

Flag

V

Differential Sense Input Voltage Range

0~±0.8

V

Output Voltage Range

V

Ambient Temperature Range

-40~125

°C



PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Ground Pin Current

15

35

50

µA

10

17

24

µA

10

17

24

µA

Output Voltage

1.55

1.5

1.45

V

Flag High

1.02

1

0.98

V

309

300

291

mV

0

15

mV

Flag Low

285

300

315

mV

0.95

1

1.05

V

1.42

1.50

1.58

V

30

ppm/ºC

Gain

10

Total Output Error (Gain + Offset)

Accuracy

±2

%

±5

%

Bandwidth

BW

300

kHz

CMRR

60

dB

Flag Trip Point

Flag TP

-2.5

+2.5

mV

Flag Low Output Voltage

60

200

mV

Flag High Leakage Current

1

µA
