U74LVC2G86

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

3 of 5

www.unisonic.com.tw

QW-R502-791.B



ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

-0.5 ~ +6.5

V

Input Voltage

-0.5 ~ +6.5

V

Output Voltage

Output in the high or low state

V

Output in the high-impedance or

power-off state

-0.5 ~ +6.5

V

±100

mA

±50

mA

-50

mA

-50

mA

Storage Temperature Range

-65 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



RECOMMENDED OPERATING CONDITIONS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Supply Voltage

Operating

1.65

5.5

V

Data retention only

1.5

V

Input Voltage

0

5.5

V

Output Voltage

High or low state

0

V

Operating Temperature

-40

85

°C

Input Transition Rise or Fall

Rate

∆t/∆v

20

ns/V

10

ns/V

5

ns/V



PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

High-level Input Voltage

V

1.7

V

2

V

V

Low-level Input Voltage

V

0.7

V

0.8

V

V

High-Level Output Voltage

V

1.2

V

1.9

V

2.4

V

2.3

V

3.8

V

Low-Level Output Voltage

0.1

V

0.45

V

0.3

V

0.4

V

0.55

V

0.55

V

Input Leakage Current

±5

μA

Power OFF Leakage Current

±10

μA
