US5V330

Preliminary

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

5 of 6

www.unisonic.com.tw

QW-R502-908.a

POWER CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS (Note 1)

MIN

TYP

(Note 2)

MAX UNIT

Quiescent Power Supply

Current

ICC

VCC=Max.

IN=GND or VCC

0.1

3.0

µA

Supply Current per Input @

TTL HIGH

∆ICC

VCC=Max.

IN=3.4V (Note 3)

2.5

Supply Current per Input per

MHz (Note 4)

ICCD

VCC=Max., S1, S2 and D Pins Open

= GND Control Input Toggling 50%

Duty Cycle

0.25

MHz

Notes:1. For Max. or Min. conditions, use appropriate value specified under Electrical Characteristics for the

applicable device.

2. Typical values are at VCC=5.0V, +25°C ambient.

3. Per TTL driven input (VIN=3.4V, control inputs only); S1, S2, and D pins do not contribute to ICC.

4. This current applies to the control inputs only and represent the current required to switch internal

capacitance at the specified frequency. The S1, S2, and D I/O pins generate no significant AC or DC

currents as they transition. This parameter is not tested, but is guaranteed by design.
