UNISONIC TECHNOLOGIES CO., LTD

ES3J

DIODE

www.unisonic.com.tw

1 of 3

Copyright © 2015 Unisonic Technologies Co., Ltd

QW-R202-035.A

SURFACE MOUNT SUPER FAST

RECTIFIER



DESCRIPTION

The UTC ES3J is a surface mount super fast rectifier, it uses

UTC’s advanced technology to provide customers with high forward

surge current and low reverse leakage, etc.

The UTC ES3J is suitable for surface mounted applications.



FEATURES

* Low reverse leakage

* High forward surge current capability



SYMBOL

SMC

(JEDEC DO-214AB)

+

-



ORDERING INFORMATION

Ordering Number

Package

Pin Assignment

Packing

Lead Free

Halogen Free

1

2

ES3JL-SMC-R

ES3JG-SMC-R

SMC

K

A

Tape Reel

Note: Pin Assignment: A: Anode

K: Cathode



MARKING

Date Code

Cathode Band for

uni-directional Only

UTC

ES3J

L: Lead Free

G: Halogen Free
