UNISONIC TECHNOLOGIES CO., LTD

S2M

Preliminary

DIODE

www.unisonic.com.tw

1 of 3

QW-R601-222.a

SURFACE MOUNT GENERAL

RECTIFIER



DESCRIPTION

The UTC S2M is a surface mount general rectifier, it uses UTC’s

advanced technology to provide customers with high forward surge

current and low reverse leakage, etc.

The UTC S2M is suitable for surface mounted applications.



FEATURES

* Low reverse leakage

* High forward surge current capability



SYMBOL

SMB

(JEDEC DO-214AA)

+

-



ORDERING INFORMATION

Ordering Number

Package

Pin Assignment

Packing

Lead Free

Halogen Free

1

2

S2ML-SMB-R

S2MG-SMB-R

SMB

K

A

Tape Reel

Note: Pin Assignment: A: Anode K: Cathode



MARKING INFORMATION

PACKAGE

MARKING

SMB
