SB260

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R601-240.C



Single phase, half wave, 60Hz, resistive or inductive load.

For capacitance load, derate current by 20%.

PARAMETER

SYMBOL

RATINGS

UNIT

DC Blocking Voltage

60

V

Working Peak Reverse Voltage

60

V

Repetitive Peak Reverse Voltage

60

V

RMS Reverse Voltage

42

V

2.0

A

Non-Repetitive Peak Forward Surge Current 8.3ms

Single Half Sine-Wave Superimposed on Rated Load

(JEDEC Method)

50

A

Operating Junction Temperature

-55~+125

°C

Storage Temperature

-55~+125

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

50

°C/W



Single phase, half wave, 60Hz, resistive or inductive load.

For capacitance load, derate current by 20%.

PARAMETER

SYMBOL

TEST CONDITIONS MIN TYP MAX UNIT

Forward Voltage Drop

0.70

V

Peak Reverse Current at Rated DC Blocking Voltage

0.5

mA

Junction Capacitance (Note 2)

190

pF

Notes: 1. Pulse width≤300μs, duty cycle≤2%.

2. Measured at 1.0MHz and applied reverse voltage of 5.0V DC.
