ADA8282
Data Sheet
Rev. 0 | Page 16 of 21
BASIC CONNECTIONS FOR A TYPICAL
APPLICATION
The ADA8282 is typically configured to operate with a nominal
3.3 V power supply, using the EPAD as the analog ground
connection. Place the bypass capacitors as close as possible to
the power supply pins to minimize the length of metal traces in
series with the bypassing paths. AC couple the inputs and
outputs for each channel as shown in Figure 30. Pull the RESET pin
low with a 10 kΩ resistor and drive it with 3.3 V GPIO logic.
The SPI pins can be directly connected to the SPI bus.
24
+OUTA
23
–OUTA
22
+OUTB
21
–OUTB
20
+OUTC
19
–OUTC
18
+OUTD
17
–OUTD
1
2
3
4
5
6
7
8
+INA
–INA
+INB
–INB
+INC
–INC
+IND
–IND
ADA8282
EPAD TIED
TO GROUND
0.1µF
0.1µF
0.1µF
0.1µF
0.1µF
0.1µF
0.1µF
0.1µF
0.1µF
0.1µF
0.1µF
0.1µF
0.1µF
0.1µF
0.1µF
0.1µF
INPUT A
SOURCE
INPUT B
SOURCE
INPUT C
SOURCE
INPUT D
SOURCE
0.1µF
0.1µF
0.1µF
0.1µF
+3.3V
+3.3V
+3.3V
GPIO: +3.3V/0V
+3.3V
10kΩ
SPI BUS
TO ADC
TO ADC
TO ADC
TO ADC
Figure 30. Typical Component Connections
