VLB10050 Type

ELECTRICAL CHARACTERISTICS

CHARACTERISTICS SPECIFICATION TABLE

Isat: When based on the inductance change rate (20% below the nominal value)

Itemp: When based on the temperature increase (Temperature increase of 40°C by self heating)

○ Measurement equipment

＊ Equivalent measurement equipment may be used.

L

Measuring

frequency

DC resistance

Part No.

Isat

Itemp

(nH)

Tolerance

(MHz)

(m

: )

tolerance(%)

(A)typ.

(A)typ.

120

±20%

1

0.35

±6

68

31

VLB10050HT-R12M

150

±20%

1

0.35

±6

52

31

VLB10050HT-R15M

200

±20%

1

0.35

±6

37

31

VLB10050HT-R20M

300

±30%

1

0.35

±6

21

31

VLB10050HT-R30N

Measurement item

Product No.

Manufacturer

L

4194A

Keysight Technologies

DC resistance

3541

HIOKI

Rated current Isat

3260+3265B

Wayne Kerr Electronics
