S3JB datasheet(1/4 Pages) TMT

部品番号	S3JB

部品情報	3A, 50V - 1000V Surface Mount Rectifiers

PDF	4 Pages

Scroll/Zoom	100%

メーカー	TMT [Taiwan Memory Technology]

ホームページ	http://www.tmtech.com.tw

Logo

1 / 4 page

CREAT BY ART

FEATURES

- Glass passivated chip junction

- Ideal for automated placement

- Low forward voltage drop

- High surge current capability

- Halogen-free according to IEC 61249-2-21 definition

MECHANICAL DATA

Case:

DO-214AA (SMB)

Molding compound, UL flammability classification rating 94V-0

Moisture sensitivity level: level 1, per J-STD-020

Part no. with suffix "H" means AEC-Q101 qualified

Packing code with suffix "G" means green compound (halogen-free)

Terminal:

Matte tin plated leads, solderable per JESD22-B102

Meet JESD 201 class 2 whisker test

Polarity:

Indicated by cathode band

Weight:

0.09 g (approximately)

VRRM

50

100

200

400

600

800

1000

V

VRMS

35

70

140

280

420

560

700

V

VDC

50

100

200

400

600

800

1000

V

IF(AV)

A

trr

μs

CJ

pF

RθJL

°C/W

TJ

°C

TSTG

°C

Note 1: Pulse test with PW=300μs, 1% duty cycle

Note 2: Reverse Recovery Test Conditions: IF=0.5A, IR=1.0A, IRR=0.25A

Note 3: Measured at 1 MHz and Applied Reverse Voltage of 4.0V D.C.

Document Number: DS_D1410018

Version: J15

Maximum reverse current @ rated VR

TJ=25°C

TJ=125°C

Taiwan Semiconductor

1.15

10

250

Typical junction capacitance (Note 3)

40

V

IR

μA

Storage temperature range

- 55 to +150

Typical reverse recovery time (Note 2)

1.5

Typical thermal resistance

10

- 55 to +150

Operating junction temperature range

Maximum instantaneous forward voltage (Note 1)

@ 3 A

VF

Maximum average forward rectified current

3

Peak forward surge current, 8.3 ms single half sine-wave

superimposed on rated load

IFSM

80

A

Maximum repetitive peak reverse voltage

Maximum RMS voltage

Maximum DC blocking voltage

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS (TA=25°C unless otherwise noted)

PARAMETER

SYMBOL

S3

AB

S3

BB

S3AB - S3MB

3A, 50V - 1000V Surface Mount Rectifiers

S3

DB

S3

GB

S3

JB

S3

KB

- Compliant to RoHS Directive 2011/65/EU and

in accordance to WEEE 2002/96/EC

DO-214AA (SMB)

S3

MB

Unit
