background image
Absolute Maximum Ratings
ADE3700
84/89
3
Electrical Specifications
3.1
Absolute Maximum Ratings
3.2
Power Consumption Matrices
*
Measured at nominal voltage supplies
**
Measured at +10% voltage supplies
*
Measured at nominal voltage supplies
**
Measured at +10% voltage supplies
Symbol
Parameter
Min.
Typ.
Max.
Unit
AVDD18
DVDD18
XVDD18
LVDD18
Supply voltage
1.95
V
AVDD33
DVDD33
Supply voltage
3.6
V
VIN
Max voltage on 5 volt tolerant input pins
6.1
V
TSTG
Storage temperature
-40
+150
°C
Table 36: ADE3700x
Symbol
Parameter
Min
Typ*
Max**
Unit
Supply Current (Analog Input, XGA@75Hz, 78.75MHz)
IAVDD18
1.8V analog supply (IAVDD18)
195
203
mA
IDVDD18
1.8V digital supply (IDVDD18)
228
257
mA
IAVDD33
3.3V analog supply (IAVDD33)
102
105
mA
IDVDD33
3.3V digital supply (IDVDD33)
4451mA
PTOTANA
Total Power Consumption (Analog Input, XGA@75Hz, 78.75MHz)
1.25
1.48
W
Table 37: ADE3700xs
Symbol
Parameter
Min
Typ*
Max**
Unit
Supply Current (Analog Input, XGA@75Hz, 135MHz)
IAVDD18
1.8V analog supply (IAVDD18)
200
207
mA
IDVDD18
1.8V digital supply (IDVDD18)
351
401
mA
IAVDD33
3.3V analog supply (IAVDD33)
104
108
mA
IDVDD33
3.3V digital supply (IDVDD33)
6880mA
PTOTANA
Total Power Consumption (Analog Input, XGA@75Hz, 135MHz)
1.56
1.89
W
