Product family data sheet

are registered trademarks and SC5 Technology and the Cree logo are trademarks of Cree, Inc. UL® and the UR logo are registered trademarks of UL LLC.

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300

Cree® XLamp® XP-G3 LEDs

ProDuCt DEsCriPtion

The XLamp® XP-G3 LeD is the highest

efficacy and most reliable LED in the

XP-G platform. Incorporating elements

of Cree’s SC5 Technology™ Platform, the

XP-G3 LED delivers both high reliability

at high operating temperatures and

high efficacy to meet the higher efficacy

and lumen maintenance requirements

of DLC classification. Optimized for

directional, high-lumen applications,

from indoor and outdoor to portable and

lamp retrofits, the XP-G3 LED delivers the

benefits of the XP-G platform – compact

and proven 3.45 mm x 3.45 mm package

and established ecosystem – enabling

customers to simplify the design process

and shorten time to market.

FEAturEs

• Available in outdoor white and 70-, 80-

and 90-CRI white

• ANSI-compatible chromaticity bins

• 3-step and 5-step options

• Binned at 85 °C

• Maximum drive current: 2000 mA

• Low thermal resistance: 3 °C/W

• Wide viewing angle: 125°

• Unlimited floor life at

≤ 30 ºC/85% RH

• Reflow solderable - JEDEC J-STD-020C

• Electrically neutral thermal path

• RoHS and REACh compliant

• UL® recognized component (E349212)

tAbLE oF ContEnts

Characteristics ............................................2

Flux Characteristics ...................................3

Relative Spectral Power Distribution ...... 11

Relative Flux vs. Junction Temperature.. 11

Electrical Characteristics......................... 12

Relative Flux vs. Current .......................... 12

Relative Chromaticity vs. Current and

Temperature ............................................. 13

Typical Spatial Distribution...................... 14

Thermal Design........................................ 14

Performance Groups – Luminous Flux... 15

Performance Groups – Chromaticity...... 16

Cree’s Standard Chromaticity Regions

Plotted on the 1931 CIE Curve ................ 20

Cree’s Standard Cool White Kits Plotted

on ANSI Standard Chromaticity

Regions..................................................... 22

Cree’s Standard Warm and Neutral

White Kits Plotted on ANSI Standard

Chromaticity Regions .............................. 24

Cree’s EasyWhite® White Kits Plotted on

ANSI Standard Chromaticity Regions..... 25

Cree’s Standard Chromaticity Kits .......... 26

Bin and Order Code Formats................... 27

Reflow Soldering Characteristics............ 28

Notes ........................................................ 29

Mechanical Dimensions .......................... 31

Tape and Reel........................................... 32

Packaging................................................. 33
