MBR5100

Preliminary

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R202-057.a



Ratings at 25°C ambient temperature unless otherwise specified.

Single phase half-wave 60Hz, resistive or inductive load, for capacitive load current derate by 20%.

PARAMETER

SYMBOL

RATINGS

UNIT

Working Peak Reverse Voltage

100

V

Repetitive Peak Reverse Voltage

100

V

Maximum RMS Reverse Voltage

70

V

DC Blocking Voltage

100

V

Average Rectified Output Current

5.0

A

Peak Forward Surge Current 8.3ms Single Half

Sine-Wave Superimposed on Rated Load

150

A

Junction Temperature

-55 ~ +150

°C

Storage Temperature

-55 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Typical Thermal Resistance

25

°C/W



ELECTRICAL CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Reverse Breakdown Voltage

150

V

0.80

V

Instantaneous Forward Voltage Drop

0.75

V

50

μA

Peak Reverse Current at Rated DC

Blocking Voltage

10

mA

Note: Pulse Test: Pulse width ≤ 300µs, Duty cycle ≤ 2%.
