RB520S40G-CC2-R datasheet(1/3 Pages) UTC

1 / 3 page

UNISONIC TECHNOLOGIES CO., LTD

RB520S40

Preliminary

SCHOTTKY DIODE

www.unisonic.com.tw

1 of 3

QW-R202-061.a

SCHOTTKY BARRIER DIODE



FEATURES

* Miniature surface mounting type

* Low forward voltage drop

* Low reverse leakage current

* Fast switching speed

SOD-523

2

1



ORDERING INFORMATION

Pin Assignment

Ordering Number

Package

1

2

Packing

RB520S40G-CC2-R

SOD-523

A

K

Tape Reel

Note: Pin Assignment: A: Anode

K: Cathode

RB520S40G-CC2-R

(1) Packing Type

(2) Package Type

(3) Green Package

(1) R: Tape Reel

(2) CC2 : SOD-523

(3) G: Halogen Free and Lead Free



MARKING
