Data Sheet

AD8420

Rev. A | Page 7 of 26

ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

Supply Voltage

±18 V

Output Short-Circuit Current

Indefinite

Maximum Voltage at −IN or +IN

−VS + 40 V

Minimum Voltage at −IN or +IN

−VS − 0.5 V

Maximum Voltage at REF or FB

+VS + 0.5 V

Minimum Voltage at REF or FB

−VS − 0.5 V

Storage Temperature Range

−65°C to +150°C

ESD

Human Body Model

4 kV

Charge Device Model

1.25 kV

Machine Model

0.2 kV

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is specified for a device in free air.

Table 5.

Package

θJA

Unit

8-Lead MSOP, 4-Layer JEDEC Board

135

°C/W

ESD CAUTION
