Rev A

PSLS01C SERIES

1 Watt

AC/DC (High Voltage DC/DC) Converter

Single Output

11/10/2016

Wall Industries, Inc. • 37 Industrial Drive, Exeter, NH 03833 • Tel: 603-778-2300 • Toll Free: 888-597-9255 •

Fax 603-778-9797

website: www.wallindustries.com • e-mail: sales@wallindustries.com

Page 7 of 7

PACKING INFORMATION

Standard Packaging

90 Degree Packaging

MODEL NUMBER SETUP

PSLS

01

C

-

1

5

B

15

S

-

F

Series Name

Output Power Covered

Isolation Votlage Input Votlage

Output Style

Ouptut Voltage

Special Mark

Package Type

01: 1 Watt

1: 3000VAC

05: 5V

Blank: Standard

09: 9V

F: 90 Degree

12: 12V

15: 15V

24: 24V

COMPANY INFORMATION

Wall Industries, Inc. has created custom and modified units for over 50 years. Our in-house research and development

engineers will provide a solution that exceeds your performance requirements on-time and on budget. Our ISO9001-2008

certification is just one example of our commitment to producing a high quality, well-documented product for our customers.

Our past projects demonstrate our commitment to you, our customer. Wall Industries, Inc. has a reputation for working closely

with its customers to ensure each solution meets or exceeds form, fit and function requirements. We will continue to provide

ongoing support for your project above and beyond the design and production phases. Give us a call today to discuss your

future projects.

Contact Wall Industries for further information:

Phone:

(603)778-2300

Toll Free:

(888)597-9255

Fax:

(603)778-9797

E-mail:

sales@wallindustries.com

Web:

www.wallindustries.com

Address:

37 Industrial Drive

Exeter, NH 03833
