FT313H USB2.0 HS Host Controller Datasheet Version 1.2

Clearance No.: FTDI# 318

6 Devices Characteristics and Ratings

6.1 Absolute Maximum Ratings

The absolute maximum ratings for the FT313H device are as follows. These are in accordance with the

Absolute Maximum Rating System (IEC 60134). Exceeding these may cause permanent damage to the

device.

Parameter

Value

Unit

Storage Temperature

-65°C to 150°C

Degrees C

Floor Life (Out of Bag) At Factory Ambient

(30°C / 60% Relative Humidity)

168 Hours

(IPC/JEDEC J-STD-033A MSL Level 3

Compliant)*

Hours

Ambient Temperature (Power Applied)

-40°C to 85°C

Degrees C

VCC Supply Voltage

0 to +5

VCC(I/O) Supply Voltage

0 to +5

DC Input Voltage – USBDP and USBDM

-0.5 to +5

DC Input Voltage – OC_N (5V tolerant)

-0.5 to +5.5

DC Input Voltage – All Other Inputs

-0.5 to +5

Table 6-1 Absolute Maximum Ratings

* If devices are stored out of the packaging beyond this time limit the devices should be baked before

use. The devices should be ramped up to a temperature of +125°C and baked for up to 17 hours.
