Revised 1/12/2016

WWW.PHIHONG.COM

5W USB Adapter with Interchangeable Plugs

PSAI05R-050QL6 Series Meets Level VI

Features

• USB Socket

• Low Leakage Current

• Field Changeable AC Plugs

• UL 94 V0 Flammability

• Ecodesign ErP Directive 2009/125/EC

level 2 annex 1b Compliant

•

DOE Level VI Compliance

Applications

• Wireless Communications

• Portable Equipment

• Peripherals

• Networking

Safety Approvals

• cUL/UL

• CE

• CB

Mechanical Characteristics

• Length: 75.3mm (2.96in)

• Height: 32.1mm (1.26in)

• Width: 35.6mm (1.4in)

Output Specifications

(1) Measured by using a 12-inch twisted pair terminal with a 10uF EC capacitor and a 0.1uF ceramic in parallel, measured at

maximum load.

(2) Registration by the country local representative may be required

Phihong is not responsible for any error, and reserves the right to make changes without notice. Please visit our website at www.phihong.com for the most

up-to-date specifications and contact information.

Model

DC Output

Voltage

Load

Ripple

(1)

Regulation

Efficiency

Min.

Max.

P-P (max.)

Line & Load

Level

PSAI05R-050QL6

5V

0A

1A

200mV

±5%
