LSM330 データシート(PDF) 13 Page - STMicroelectronics |
|
|
|||||||||||||||||||||||||||||
LSM330 データシート(HTML) 13 Page - STMicroelectronics |
|
|
13 / 75 page  DocID023426 Rev 3 13/75 LSM330 Block diagram and pin description 75 10 INT1_G Gyroscope interrupt signal 11 INT1_A Accelerometer interrupt1 signal 12 INT2_A Accelerometer interrupt2 signal 13 DEN_G Gyroscope Data Enable 14 Res Reserved. Connect to GND 15 Res Reserved. Connect to GND 16 Res Reserved. Connect to GND 17 Res Reserved. Connect to GND 18 Res Reserved. Connect to GND 19 GND 0 V supply 20 GND 0 V supply 21 CAP Connect to GND with ceramic capacitor(2) 22 Vdd(3) Power supply 23 Vdd(3) Power supply 24 Vdd(3) Power supply 1. 100 nF filter capacitor recommended. 2. 10 nF (+/- 10%), 25 V. 1nF minimum value has to be guaranteed under 11 V bias condition1. 3. 100 nF plus 10 μF capacitors recommended. Table 2. Pin description (continued) Pin # Name Function |
|
