AMS00x • Embedded Bluetooth Low Energy Solution

Packaging, Handling & Storage, RoHS, Section 8

ADS-MS00x-107R • Preliminary Data Sheet

Page | 22

September 14, 2015

8.3 Handling & Storage

CAUTION

MSL3 Sensitive Device!

AMS00x modules are moisture sensitive devices rated

at Moisture Sensitive Level 3 (MSL3) per IPC/JEDEC

J-STD-20.

After opening the moisture sealed storage bag, mod-

ules that will be subjected to reflow solder or other

high temperature processes must be:

1. mounted to a circuit board within 168 hours at

factory conditions (≤30°C and <60% RH)

2. continuously stored per IPC/JEDEC J-STD-033

Modules that have been exposed to moisture and envi-

ronmental conditions exceeding packaging and storage

conditions MUST be baked before mounting according

to IPC/JEDEC J-STD-033.

Failure to meet packaging and storage conditions will

result in irreparable damage to modules during solder

reflow.

8.4 RoHS Directive

Each AMS00x module is produced

according to the RoHS (Restriction

of the use of certain Hazardous

Substances in electrical and electronic equipment) di-

rective and complies with the directive.
